HZS50 Concrete Batching Plant

HZS50 Concrete Batching Plant

BrandHua Ning
Power90kw
Weight--
Dimension(L*w*h)--
24-Hour Online Service
Global Service Network
Technical Solutions

Specifications

Brief Introduction
Concrete Batching Plant is consisted of mixing system, material weighing system,  feeding system, electrical system and other auxiliary facilities (such as air compressor, water pump, control system etc.).
 HZS series of concrete mixing plant is developed by our company on the basis of adopting the world's sophisticated technologies, this concrete mixing plant have been widely used in the domestic and overboard,  as well as waterconservancy ,electric power, railroad,  road,  tunnel , the arch of bridge, harbor-wharf and the national defense-project etc.

Main Parts
· Theoretical productivity: 50 m3/h
· Mixing Machine: JS1000
· Aggregate Batcher Machine: PLD1600 with 3 storage bins;
· Cement Silo: 100T boltd type (it depends on the customer's choice);
· Screw Conveyor: LSY219

Characteristics
· Reliable working performance
· High efficient compulsory concrete mixer
· Accurate batching system
· Full Automatic Control System
· Excellent environmental protection, dust collection system and anti-noise design.


Technical

Model HZS50
The Whole Station Max. Productivity 50 m3/h
Discharge Height 1.5-3.8 m
Working Cycle 72 s
Dimension (LxWxH) 15922x13500x17750 mm
Power 90 kw
Concrete Mixer JS1000
Batching Machine PLD1600
Pneumatic system Air Compressor Model 1.5-7
Nominal Displacement 1.67 m3/min
Rated Discharge Pressure 0.8 mpa
Motor power 7.5 kw
Measurement Accuracy of Weighing system Aggregate ±2%
Cement ±1%
Water ±1%
Admixture ±1%
