JDC500 Electric Single-shaft Concrete Mixer

JDC500 Electric Single-shaft Concrete Mixer

BrandHua Ning
Power29.1kw
Weight3700kg
Dimension(L*w*h)4330×2700×5000mm
24-Hour Online Service
Global Service Network
Technical Solutions

Specifications

Brief Introduction:
JDC500 Concrete Mixer can mix various mix of plastic concrete, dry rigid concrete, lightweight aggregate concrete and various mortar.
The mixing system is driven by cylindrical gears, and the drive is very reliable. Feeding mechanism adopts lifting motor with high safety.
The concrete mixer can work together with the batching machine to form a small mixing plant.
JDC concrete mixer is ideal for a variety of construction sites, small and medium construction projects, precast concrete factories.

Advantages:
1. Final products are discharged much quickly and cleanly
2. Power-driven discharge
3. High mixing quality; easy maintenance
4. Long service life of liner and blades
5. Easy to control, easy to move
6. Wide applications, high production efficiency, low energy consumption, low noise, reasonable structure, convenient operation, etc.





Technical

Model JDC350 JDC500
Discharge Capacity (L) 350 500
Feeding Capacity (L) 560 800
Theoretical Productivity (m3/h) 15-20 20-30
Max. aggregate Size: Pebble/Gravel (mm) 40/60 60/80
Mixing Motor Power (kw) 15 18.5
Lifting Motor Power (kw) 4.5 5.5
Discharge Motor Power (kw) 4 4
Pump Motor Power (kw) 0.75 1.1
Hopper Lifting Speed (m/min) 18 18
Dimensions (L×W×H)  (mm) 4150×2700×3150 4330×2700×5000
Weight (kg) 3000 3700
